2m 16mm2 6 Gauge Welding Cable AUSTRALIAN MADE
$37.00
Product Introduction
2m Australian made welding cable with 16mm2 (6 Gauge) 100% oxygen free copper conductors. Double insulated NBR/NBR outer shell (90oC rated), soft and flexible for welding applications, compliant to AS1995:2003.
Specifications
| Length | 2m |
| Cross Section | 16mm2 (6 Gauge) |
| Max Current | 250 Amp (30% Duty Cycle) |
| Conductor | High Purity Copper |
| Insulation | Double Insulated NBR/NBR (90oC) |
2m Welding Cable – 16mm2 – 6 Gauge – Solar – Car Stereo AUSTRALIAN MADE
Looking for a high-performance welding cable that delivers reliability and flexibility for your projects? Our 2m Australian-made welding cable is engineered to meet the demands of professional welders and DIY enthusiasts alike. Crafted with premium materials and strict compliance with industry standards, this cable ensures optimal conductivity and durability, making it the ideal choice for various welding applications.
Core Parameters
| Length | 2m (single continuous length) |
| Cross-Sectional Area | 16mm2 |
| Gauge | 6 AWG/B&S |
| Max Current | 250 Amp (30% Duty Cycle) |
| Conductor Material | 100% Oxygen-Free Copper (extra fine strands) |
| Insulation | Double Insulated NBR/NBR (V90HT rated, 90oC) |
| Compliance | AS1995:2003 |
| Flexibility | Soft and highly flexible design |
| Origin | AUSTRALIAN MADE |
| Equivalent Part | UNIMIG WC16MM / U51025 |
Key Features & Benefits
High Purity Copper Conductors: 100% oxygen-free copper with extra fine strands ensures excellent voltage conductivity, minimizing power loss and maximizing welding efficiency.
Double Insulation: NBR/NBR double insulation rated to 90oC (V90HT) provides superior heat resistance and protection against abrasion, chemicals, and mechanical damage.
Exceptional Flexibility: Unique softness allows easy maneuverability in tight spaces, reducing operator fatigue during extended use.
Australian Quality: Manufactured locally to meet strict AS1995:2003 standards, guaranteeing reliability and performance for professional welding applications.
Applications
Ideal for all welding applications, including MIG, TIG, and arc welding. Suitable for use with welding machines, solar power systems, car stereos, and other heavy-duty electrical connections where high current and flexibility are required.
Why Choose Our Welding Cable?
Unlike generic cables, our Powerflex welding cable combines Australian craftsmanship with premium materials. The extra fine copper strands enhance flexibility without compromising conductivity, while the double insulation ensures long-term durability in harsh environments. It¡¯s the perfect balance of performance and reliability for both professional and hobbyist use.
FAQ
Q: What is the maximum current this cable can handle?
A: 250 Amp at 30% Duty Cycle (see photos for alternate duty cycle specifications).
Q: Is the cable suitable for outdoor use?
A: Yes, the double NBR insulation provides weather and chemical resistance, making it suitable for indoor and outdoor applications.
Q: Can this cable be used for solar installations?
A: Absolutely, its high conductivity and durability make it ideal for solar power system connections.
Ready to Upgrade Your Welding Setup?
Experience the difference with Australian-made quality. Contact us today to discuss your requirements, request a quote, or learn more about how this welding cable can enhance your projects. Send us an inquiry now!
