40m 25mm2 3 Gauge Welding Cable Australian Made
$509.00
Product Introduction
Australian made 40m welding cable with 25mm2 (3 Gauge) 100% oxygen free copper conductors. Double insulated NBR/NBR to V90HT, soft, flexible, ideal for welding applications, complying to AS1995:2003.
Specifications
| Length | 40m |
| Cross Section | 25mm2 (3 Gauge AWG/B&S) |
| Max Current | 333 Amp (30% Duty Cycle) |
| Material | 100% Oxygen Free Copper |
| Insulation | Double NBR/NBR, V90HT (90oC rated) |
40m Welding Cable – 25mm2 – 3 Gauge – Solar Car Battery Stereo AUSTRALIAN MADE
Why Choose Our Australian-Made Welding Cable?
When it comes to welding applications, reliability and performance are non-negotiable. Our 40m Powerflex Welding Cable is engineered to deliver exceptional results in the most demanding environments. Made in Australia with 100% oxygen-free copper, this cable combines superior conductivity, flexibility, and durability¡ªperfect for professionals and DIY enthusiasts alike.
Core Specifications
| Length | 40 meters |
| Cross-Sectional Area | 25mm2 |
| Gauge (AWG/B&S) | 3 Gauge |
| Max Current (30% Duty Cycle) | 333 Amp |
| Conductor Material | 100% Oxygen-Free Copper |
| Insulation | Double Insulated NBR/NBR |
| Temperature Rating | V90HT (90oC) |
| Compliance | AS1995:2003 |
| Origin | Australian Made |
| UNIMIG Equivalent Part | WC25MM / U51026 |
Key Features & Benefits
- High Purity Copper Conductors: Extra fine strands ensure excellent voltage conductivity and minimal power loss.
- Superior Flexibility: Unique softness allows easy maneuvering in tight spaces, reducing operator fatigue.
- Double Insulation: NBR/NBR outer shell provides resistance to heat, oil, and abrasion for long-lasting performance.
- Australian Quality: Manufactured locally to strict standards, guaranteeing reliability and safety.
Applications
Ideal for welding machines, solar installations, car batteries, stereo systems, and industrial power distribution. Suitable for both indoor and outdoor use in workshops, construction sites, and automotive garages.
Performance You Can Trust
Tested to withstand extreme temperatures and heavy-duty use, this cable ensures stable current flow even under high load. The 30% duty cycle rating (333 Amp) makes it suitable for continuous welding operations¡ªsee product photos for detailed duty cycle specifications.
Why Our Cable Stands Out
Unlike generic cables, our Powerflex model offers:
– Oxygen-Free Copper: Prevents corrosion and ensures maximum conductivity.
– Double Insulation: Enhanced safety compared to single-layer alternatives.
– Australian Manufacturing: Supporting local quality and reducing supply chain delays.
FAQ
Q: What is the maximum temperature this cable can handle?
A: It is rated for 90oC (V90HT), suitable for high-heat welding environments.
Q: Is this cable compatible with UNIMIG equipment?
A: Yes, it is equivalent to UNIMIG part # WC25MM / U51026.
Q: Can I use this for solar battery connections?
A: Absolutely¡ªits high conductivity makes it ideal for solar and battery applications.
Ready to Upgrade Your Welding Setup?
Don¡¯t compromise on quality. Our Australian-made welding cable delivers the performance and durability your projects demand. Contact us today for a quote or to learn more about bulk pricing options!
