Kemppi Minarc T 223 ACDC TIG Welder 4m Torch
$5,700.00
Product Introduction
Minarc T 223 ACDC GM is a 220A single-phase AC/DC TIG welder with built-in electrolytic weld cleaning. Portable multi-voltage design enables high-quality TIG welding and professional weld cleaning on-site. Features Auto Pulse, AC frequency control, memory channels, and a large color display for easy operation.
Key Specifications
| Output Current | 220A (20% duty cycle) |
| Voltage Range | 110-120V ¡À10%, 220-240V ¡À10% |
| Functions | AC/DC TIG, DC+/- MMA, WeldClean |
| Weight | 16.8kg |
| Protection Class | IP23 |
Kemppi Minarc T 223 ACDC TIG Welder – Gas Cooled 4m Torch
Transform your welding projects with the Kemppi Minarc T 223 ACDC GM, a revolutionary 220A single-phase AC/DC TIG welder that combines high-quality welding and professional electrolytic weld cleaning in one portable machine. Whether you’re working on-site or in the workshop, this versatile tool delivers perfect results with unmatched efficiency.
Core Specifications
| Output Current (20% ED) | 220A |
| Voltage Compatibility | 110-120V / 220-240V ¡À10% |
| WeldClean Function | Built-in electrolytic cleaning |
| Auto Pulse | With frequency control |
| Memory Channels | 4 programmable settings |
| Open Circuit Voltage | 23V |
| Stick Electrode Size | 1.6mm – 4.0mm |
| Degree of Protection | IP23 |
| Weight | 16.8kg |
| Operating Temp Range | -20¡ãC to +40¡ãC |
Key Features & Benefits
All-in-One Solution: Perform TIG welding and weld cleaning in one setup, eliminating post-processing delays. The MAX WeldClean system uses electric current and phosphoric acid to remove oxidation instantly.
Multi-Voltage Flexibility: Operates on both 110-120V and 220-240V power sources, making it ideal for global job sites.
Precision Control: Auto Pulse, AC balance, and frequency adjustment ensure superior weld quality on aluminum, stainless steel, and other metals.
User-Friendly Interface: Large color LCD with impact protection offers clear settings visibility in any lighting condition.
Portable Design: Weighing only 16.8kg with optional transport carts, it¡¯s easy to maneuver on-site.
Applications
Perfect for metal fabrication, automotive repair, aerospace components, and industrial maintenance. Ideal for professionals needing high-quality TIG welds with minimal post-processing.
Why Choose Minarc T 223 ACDC?
Unlike conventional welders, this machine integrates cleaning functionality, reducing workflow time by up to 50%. Its rugged IP23 rating and wide temperature tolerance ensure reliability in harsh environments. Backed by Kemppi¡¯s decades of welding expertise, it¡¯s built to deliver consistent performance.
FAQ
Q: What materials can it weld?
A: Aluminum, stainless steel, carbon steel, and other ferrous/non-ferrous metals.
Q: Does it include a foot pedal?
A: The FR41 wired foot pedal is available as an optional accessory.
Q: Can I use it with a generator?
A: Yes, requires minimum 8kVA generator power.
Ready to elevate your welding productivity? Contact us today for technical details, pricing, and availability.
